Tornado

The Mandako Tornado is a 10’ tillage tool with dual independent coulter mounts and a blade angle you change on the go, from 0–14°. Put the 13 Wave blades on it and it runs as Vertical Till; the Samurai is Minimum Till; the Concave turns it into a High-Speed Till machine. Disc spacing is 5″ and the tractor needs 150+ HP.

Key Advantages

Three blade sets on one frame, so one machine covers vertical, minimum and high-speed tillage.
Hydraulic blade angle adjustment from 0–14° without stopping.
Dual independent spring trip coulters: a rock lifts one blade, the rest keep cutting.
16″ baskets or the AR400 rolling spike harrow behind the discs for the finish you want.
Quick-change hubs with triple-lip seals and colour-coded hydraulics.

Core Features

Dual independent spring trip coulters.
Hydraulic blade angle adjustment: 0–14°.
16″ Heavy-Duty rolling baskets (Flat).
NEW: AR400 Rolling Spike Harrow for a harder finish.
Quick-change coulter hubs with triple-lip seals.
Hydraulic single-point depth control; hydraulic leveling kit.
5″ disc spacing.
LED lighting package; color-coded hydraulic handles.
Heavy-duty hubs and spindles; Grade 50 materials.

Blade Options

13 Wave

Vertical Till

Sizes residue and mixes it into the top few inches so it breaks down faster.
Opens the soil with the least disturbance of the three blades.
Leaves residue on the surface, which holds moisture and topsoil in place.
Runs wet or dry without smearing a layer under the blade.
The blade to take for fracturing, not for moving dirt.

Samurai

Minimum Till

Serrated and self-sharpening, so the edge stays through the season.
Cuts heavy residue and sod that stops a plain blade.
Works in all weather conditions.
The blade for grassland work and hay ground.
Opens wet soil so it dries and airs out.

Concave

High-Speed Till

Built to be driven fast, which is where the acres per hour come from.
Chops crop residue and works it in rather than leaving it whole on top.
Set shallow or deep with the same single-point control.
Serrated and self-sharpening.
Works best with the blade angle between 5–14°.

*All coulter blades are heat-treated for durability and longevity.

Finishing & Residue Management Tools

16″ Heavy-Duty Rolling Baskets — **16″ Heavy-Duty Baskets (Flat)** — break clods and firm the seedbed behind the discs.

Mandako Rolling Spike Harrow — **Rolling Spike Harrow (NEW)** — AR400 spikes for ground that needs breaking up rather than smoothing over.

Available Options

Clevis hitch insert.
Available in Mandako Green or Black.
10’ unit, 10‘4” working width, 10,008 lbs, 3 hydraulic ports and 5GPM at 2800 PSI, IF320/70R15 tires.

Request a quote

Advantages of the model

Three blades, one frame

13 Wave for vertical tillage, Samurai for minimum till and sod, Concave for high-speed work. The blade set decides what the machine is, and the 0–14° hydraulic angle fine-tunes it in the field.

Residue sized, not buried

The discs cut and mix crop residue at 5″ spacing instead of turning it under, and the baskets or the AR400 spike harrow level what is left. The seedbed comes out even in one pass.

Coulters that trip on their own

Dual independent spring trip coulters on quick-change hubs with triple-lip seals. A rock lifts one blade and the rest keep cutting; a damaged blade comes off without pulling a gang apart. Grade 50 steel through the frame.

Set from the seat

Hydraulic single-point depth control, hydraulic blade angle and a hydraulic levelling kit, with colour-coded handles so hookup takes a minute. Three ports and 5GPM at 2800 PSI is what the tractor has to supply.

TORNADO SPECIFICATIONS

Unit Size	10’
Transport Length (A) (approx)	27‘8”
Transport Width (B) (approx)	12’1“
Overall Width (C) (approx)	10‘4”
Working Width (D) (approx)	10‘4”
Overall Height (E) (approx)	5’10“
Weight (lbs) (approx)	10,008
Hyd. Red. (Ports)	3
Hyd. Red. (@2800 PSI)	5GPM
Horespower Red.	150+
Tire Size	IF320/70R15

Brochure

The Tornado brochure as a PDF: blade options, finishing tools and the specification table on one sheet.

open pdf

Dealers

VIEW AS A LIST

Send us your details and we will get back to you, or point you to the nearest dealer.


   Mandako Agri Marketing (2010) Ltd
   25 Google reviews
  Write a review






       Posted on Google

   RAJVIR SINGH CHAHAL



 Trustindex verifies that the original source of the review is Google. I’m jas rb driver off loading here good service and friendly


      Posted on Google

   Sergey Stadnik



 Trustindex verifies that the original source of the review is Google. The best company in its segment!


      Posted on Google

   J Y



 Trustindex verifies that the original source of the review is Google. We purchased a new land roller and discovered that one drum was defective. The service guys came out promptly to inspect it and a couple days later replaced it. Excellent company to deal with. Excellent product. Excellent service. They make it right.


      Posted on Google

   Curtis Sutter



 Trustindex verifies that the original source of the review is Google. We've had their landroller for quite some time. Very heavy and well built. One might think that something as simple as a landroller would have little difference between manufactures, but it would seem those people have never tried a Mandako roller. They also stand behind their products 110% and are very easy to talk to and deal with.


      Posted on Google

   Chad Ellis



 Trustindex verifies that the original source of the review is Google. You wouldn’t be disappointed with this company. I often delivered raw steel to them. And witness how they built their products.
Staffs are awesome btw !!! 😃

Have a question?

Below are the questions our dealers hear most often about the Tornado. If yours is not here, call us or send it through the form at the bottom of the page.

What makes the Tornado different from other tillage machines?

The blade set. Three options fit the same frame — 13 Wave, Samurai and Concave — and the hydraulic angle moves 0–14° while you drive, so one machine does vertical, minimum or high-speed tillage instead of three.

Can the Tornado handle heavy residue and tough field conditions?

Corn stalks and prairie sod are what the Samurai blade is for; it is serrated and self-sharpening and cuts what a plain blade rides over. The Concave chops and incorporates at speed. Behind either, 16″ baskets or the AR400 rolling spike harrow level the field.

How easy is it to adjust and maintain the Tornado?

Depth is hydraulic single-point, blade angle is hydraulic and on the go, and the levelling kit is hydraulic too. Coulter hubs are quick-change with triple-lip seals, and the hydraulic handles are colour-coded.

What kind of tractor power does the Tornado require?

150+ HP, three hydraulic ports and 5GPM at 2800 PSI. The machine weighs about 10,008 lbs and rides on IF320/70R15 tires, so it is a mid-size tractor job rather than a four-wheel-drive one.

Which blade should I order?

13 Wave if you want to fracture soil and size residue with the least disturbance. Samurai if you cut sod, hay ground or heavy trash. Concave if you cover acres fast and want residue chopped in. All three are heat-treated.
